LW serial decanter centrifuge has two control models of variable frequency and work frequency, and has abovementioned various decanter centrifuges devoted for ocean drilling platforms. The work frequency-driven decanter centrifuge can change its speed through pulley and belt change, and the variable frequency horizontal centrifuge can realize infinite speed variation in a large scope and its control cabinet can directly display the parameters of work rev., work current and torque. The engine may be suitable for power grids of 50Hz and 60Hz.
Basic Characterstics of TRLW Serial Mud Centrifuge
- Genuine NSK/FAG bearing.
- Screw protection: Ceramic Tiles for longer life and easier replacement.
- Other Parts of the bowl assembly material: stainless steel SS316L.
- Bowl Cylindrical and Conical section made from Duplex Stainless Steel.
- Easily adjustable liquid discharge weir height for flexible application.
- Screw flow distribution port and bowl solids discharge port protected by tungsten carbide alloy.
- Bowl assembly supported by tighten belt for protection of bearing inmoving.
- Pressurized EX Proof VFD control cabinet.
Technical Parameters of TR Oilfield Decanter Centrifuge
| Model | TRLW450N-3 | TRLW550N-1 |
| Bowl Diameter | 450mm | 550mm |
| Bowl Length | 1600mm | 1800mm |
| Max Capacity | 70m 3 /h | 90m 3 /h |
| Rotary Speed | 2800r/min | 2600r/min |
| G-Force | 2578 | 2711 |
| Main Motor Power | 45kW | 55kW |
| Auxiliary Motor Power | 15kW | 22kw |
| Separation point | 2~5μm | 2~5μm |
| Weight | 4500kg | 5800kg |
| Dimension | 2950x1860x1250mm | 3250x1960x1350mm |
(Note: Rotary speed can be adjustable as per user's requirements)
TR Solids Control is a lead and professional manufacturer of decanter centrifuge. TR decanter centrifuge is high in recovery rate, effective in solids control and remarkable in the reduction of cost spent on drilling mud resupplying and management. Separation point of TR decanter centrifuge can meet as fine as 2~7 microns.
Our Services
1. We are a professional and well-know manufacturer of decanter centrifuge with more than 10 years experience.
2. Our factory has Automantic production line.
3. We have quality management system and relevant certificates.
4. 24 hours oversea service online.
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
